- 1. Housing
- 2. Fill/Drain Plug
- 2A. Fill Plug O-Ring
- 3. Discharge O-Ring (BSP Housing Only)
- 4. Housing O-Ring
- 5. Inner Volute O-Ring
- 6. Separator Plate
- 7. Inner Volute
- 8. Impeller Assembly
- 8A. Impeller Thrust Ring Only
- 9. Impeller Drive
- 9A. Impeller Bushing Only
- 10. Impeller Shaft
- 11. Barrier
- 12. Barrier O-Ring (NEMA Motors Only)
- 13. Clamp Ring
- 14. Clamp Ring O-Ring (NEMA Motors only)
- 15. Motor Adapter
- 16. Motor Adapter O-Ring (NEMA Motors only)
|
- 17. Drive Magnet Assembly with Retaining Ring
- 17A. Retaining Ring Only
- 17B. Set Screws
- 18. Motor Adapter Flange (IEC Motors Only)
- 19. Housing Bolt
- 20. Housing Lock Washer
- 21, Housing Flat Washer
- 22. Clamp Ring Flat Washer
- 23. Clamp Ring Lock Washer
- 24. Clamp Ring Bolt
- 25. Drive Bolt (IEC Only)
- 26. Drive Lock Washer (IEC Only)
- 27. Drive Flat Washer (IEC Only)
- 28. Motor Adapter Bolt
- 29. Motor Adapter Lock Washer
- 30. Motor Adapter Flat Washer
- 31. Motor Adapter Flange Bolt (IEC Only)
- 32. Motor Adapter Lock Washer (IEC Only)
- 33. Motor Adapter Flat Washer (IEC Only)
|
