Brontz Gear Pump/ Big Flow

High Viscosity Gear Pump

UK BRONTZ high viscosity gear pump is based on European progressive production technology designed & developed specially for middle-high viscosity materials. UK BRONTZ Industrial Group Ltd. is headquartered in London UK, is a famous British fluid equipment manufacturing company, the company have 4 affiliated factories, which are located in France, the Netherlands, Italy, Sweden and the other places, in the industrial pump and fluid machinery equipment research and development has a wealth of experience, also a group-type supplier integrating technical advice, product sales & supporting services, its products are widely used in the domestic chemical, petrochemical, fine chemicals, light industry, papermaking, machinery, environment protection, medicine, daily chemical, metallurgy, textile, printing & dyeing, chemical fiber, electronic, paint coating, lubricating oil and hydraulic system etc., in order to service our customers better, we adopt the sales model of agents, authorized agents will provide customers same price and service.

PRODUCTS CHARACTERS

As a global fluid equipment manufacturing company, in Europe has a high standard of production lines, BRONTZ has been innovating, designing, manufacturing parts, to make pump performance reach a new height.
Our products highlight the advantages: modular design, long life, low maintenance costs.
BRONTZ has an experienced technical team, who can provide you pre-sale, sale, after-sale technical support and perfect one-stop service.

■   Excellent workmanship, short lead time
■   Modular design, save maintenance cost and time
■   Sturdy & durable pump body, simple design
■   Many standard configuration for selection
■   Adopting pull-back design
■   Gear gap axial direction adjusting
■   Delivery both-way (advise relative technical requests before selection)

PRODUCT DESCRIPTION

Product Series	Characteristics & Performance
	G-MAX Series Heavy Duty Type Flowrate：250 m3/h (1100GPM) Pressure: Max.20 Bar (290PSI) Max. Speed：1750 rpm Viscosity Range：Max.250000 cst Max. Temperature：250℃，electric torch、conduction oil、steam or hot water heating Sealing：single/double mechanical seal、packing seal Self-suction Height：Max.0.5Bar vacuum when self-suction; Max.0.8Bar vacuum when delivering Connection Method：Pipeline thread connection or ANSI flange connection
	GT Series General Compact Type Flowrate：50 m3/h (1100GPM)Pressure： Max.18 Bar (261PSI)Max. Speed：1750 rpmViscosity Range：Max.250000 cst Max. Temperature：150℃， Sealing：Mechanical Seal Self-suction Height：Max.0.5Bar vacuum when self-suction; Max.0.8Bar vacuum when delivering Connection Method：Pipeline thread connection or ANSI flange connection
	NE Series Gear Magnetic Pumping Flowrate：250 m3/h (1100GPM)Pressure：Max.20 Bar (290PSI)Max. Speed：1750 rpmViscosity Speed：Max.250000 cst Max. Temperature：250℃，electric torch、conduction oil、steam or hot water heating Self-suction Height：Max.0.5Bar vacuum when self-suction; Max.0.8Bar vacuum when delivering Connection Method：Pipeline thread connection or ANSI flange connection

INTERNAL GEAR PUMP APPLICATION

Painting, rubber solution, mucilage glue, latex, emulsion, essence, resin, adhesive emulsion, wax, glycerinum, printing ink, ink, dyestuff, sodium silicate, lye, lubricating oil, fuel oil, fatlute, syrup, molasses, conduction oil, rosin, kerosene, oil, polyester, hardener, polyol, isocyanate.Our magnetic gear pump will be helpful for all these high viscosity mediums.

MATCHING EQUIPMENTS

Textile printing machine, polyester equipment, chocolate equipment,lubricating oil cycle, fuel delivering, Asphalt machinery etc.
